| Place of Origin: | CHINA |
| Certification: | ISO,CE |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden cases standard export package |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 200-500 Sets/Month |
| Name: | Green Laser Marking Machine | Application: | Laser Marking |
|---|---|---|---|
| Laser Type: | Green Laser | Working Accuracy: | ±0.001mm |
| Condition: | New | CNC Or Not: | Yes |
| Cooling Mode: | Air Cooling | Laser Wavelength: | 532nm |
| Laser Power: | 3W | Dimension(L*W*H): | 700x245x460mm |
| Marking Speed: | ≤7000mm/s | Min Liner Width: | 0.05mm |
| Working Area: | 70x70mm 110x110mm(optional) | Applicable: | Crytal ,Metal,plastic,Hard Plastic |
| High Light: | 3w Fiber Laser Marking Machine,532nm Portable Laser Marker Machine,7000mm/S Portable Metal Marking Machine |
||
3W Green Laser Source Portable Fiber Laser Marking Machine
|
Model |
LB-MG3 |
|
Laser Power |
3W |
|
Laser Wavelength |
532nm |
|
Beam Quality |
M2≤1.2 |
|
Laser Repetition Frequency |
20KHz~200KHz |
|
Working Area |
110x110mm |
|
Marking Speed |
≤7000mm/s |
|
Min. Line Width |
0.03mm |
|
Repeated Precision |
±0.001mm |
|
Cooling System |
Air-cooling |
|
Power Supply |
220V / 50Hz |
|
Power Consumption |
0.8KW |
|
Dimension |
700x245x460mm |
Standard Accessories (Portable Fiber Laser Marker)
(1) A set of 3W Green Laser Source
(2) A set of Digital Scanning System
(3) A set of high-speed Scan Lens (Singapore Ronar-Smith)
(4) 110mm x110mm Fiber Focus Lens (Singapore Ronar-Smith)
(5) A set of Laser Beam Expanders (Singapore Ronar-Smith)
(6) Motion control card
(7) A set of marking control system
(8) A set of marking software
(9) A pedal switch
(10) Working table(200mmX150mm)
(11) Laser power supply
(12) "Operation instruction","Training Video”
Machine Features
1. Laser device belongs to cold light source, small heating area, and excellent beam quality to create ultra-fine marking effects.
2. Tidy borders, no explosion point, no thermal deformation, it can effectively increase the rate of finished products.
3. Laser device with stable performance, long service life, maintenance-free, no consumables, and low operation cost.
4. Adopted imported scanning galvanometer with fast marking, the smallest spot can reach 15um after focusing, it is extremely suitable for micro cutting and drilling.
